| Interfaces | 8-Port 1Gbps SFP
16-Port 1Gbps/2.5Gbps SFP
4-Slot 10Gbps SFP+
|
|---|
| Console Port | RJ-45 to RS-232
|
|---|
| Memory | 512MB DDR3 SDRAM
|
|---|
| Flash | NOR 64MB, NAND 1GB
|
|---|
| Memory | 512MB DDR3 SDRAM (Option 1GB)
|
|---|
| Switching Capacity | 180Gbps
|
|---|
| Throughput | 133.9Mpps
|
|---|
| MAC | 32K
|
|---|
| L2 Features | GARP
• Port-based VLAN,
• IEEE 802.1q Tag VLAN
• MAC-VLAN, Protocol-VLAN, Subnet-VLAN
• Private VLAN
• VLAN Translation n-to-1
• Voice VLAN (Auto VoIP)
• Spanning Tree Protocol (STP/RSTP/MSTP)
• 802.3ad Link Aggregation
• Port Mirroring (Ingress/egress)
• MVR
|
|---|
| L3 Features | Static Routing
RIPv1/v2, OSPFv3, BGPv4, VRRP
Multiple Default Gateway
|
|---|
| QoS | Classification (L2/L3/L4)
• 8 Queues per Port
• Mark/Remark/Policing
• Traffic Scheduling (SP, DWRR)
• Traffic Policing and Shaping
• Rate Limiting |
|---|
| Security | Storm Control (Unicast, Broadcast, Multicast)
802.1x Authentication
L2/L3/L4 based ACL
IP Packet Filtering
DoS Protection
|
|---|
| Sync. & OAM | Service enabled PB (JPS)
E-LINE (EPL, EVPL)
E-LAN (EP-LAN, EVP-LAN)
- IEEE 1588 PTP(Precision Time Protocol)
- NTPv4 Client
Link OAM (IEEE 802.3ah)
Flow OAM (IEEE 802.3ag/Y.1731)
|
|---|
| Management | CLI(serial / Telnet)
• Remote FW Upgrade (Web)
• Remote Configuration Upgrade
• Port Mirroring
• SNMP v1/v2c/v3, SNMP Trap
• Logs (Buffered, Cmd, Sys, Trap, Event)
• sFlow
• TACACS+, RADIUS, SSH, RMON
• LLDP
• DHCP Server, Relay Agent (option82) |
|---|
| 정격전원 | AC 90~250V, 50/60Hz 전원 이중화 지원 |
|---|
| 소비전력 | Max. 33W
|
|---|
| 크기 | 440(W) * 246(D) * 44(H) mm
|
|---|
| 무게 | 약 3.2kg
|
|---|
| 온도 | 동작온도: -40°C ~ 80°C
보관온도: -40°C ~ 85°C
|
|---|
| 습도 | 5% ~ 95% (non Condensing)
|
|---|
| LED, Display | Power1, Power2, RUN, Port Link/Act
|
|---|
| Multicast | • IGMP v1/v2/v3 Snooping
• IGMP Static Join
• IGMP Redundancy Proxy
|
|---|
| IPv6 | • Dual Stack (IPv4/IPv6)
• DHCPv6 (Server/Relay/Snooping)
• MLD Snooping v1/v2, MLD v1/v2
• OSPFv3, BGP4, Static Routing
• QoS and Security for IPv6
• Management for IPv6 |
|---|
